1522 7" 2/L VIDEO WAY KIT

Description

The WAY 2/L video intercom is a state-of-the-art communication system for homes and buildings. It offers high image quality, easy installation, and compatibility with additional CCTV cameras. It includes a rugged outdoor panel with a sun visor , two 7" touchscreen monitors , and a powerful DIN power supply to ensure stable and efficient operation.

Kit components:

• WAY 2/L plate with visor (Ref. 1528)
• 2 WAY 7" Monitors (Ref. 1525)
• DIN8 26DC-2A power supply (Ref. 1440)

System extensions:

• Housing: Support up to 3 monitors without additional power supply.
• Street panel: Supports the installation of a second street panel.
• Additional cameras: Each outdoor panel supports an additional CCTV camera (max. 2).

Technical Specifications

WAY 2/L Street Sign (Ref. 1528)

• Mounting: Surface, with rain visor included.
• Material: High resistance Zamak.
• Camera: HD 900 TVL resolution, color night vision with 6 LEDs, H=120º and V=90º angles.
• Connections:
  • Electric door opener (S+, S-).
  • Relay configured as NO/NC for garage door (COM, NO/NC).
  • Entrance hall exit button.
  • Connection for additional CCTV camera.

WAY 7" Monitor (Ref. 1525)

• 7” touch screen with intuitive interface.
• Do not disturb mode with LED indicator.
• Automatic and manual capture of photos and videos with storage of up to 1,000 images on MicroSD (not included).
• Internal intercom function between monitors.
• Support for CCTV cameras (one camera per plate).
• Call history with date and time stamp .
• Customizable image and volume adjustment options.
• Supports up to three monitors per home without an additional power supply.

DIN8 26DC-2A power supply (Ref. 1440)

• Input: 100-240Vac, 0.6A (50-60Hz).
• Output: 26Vdc, 2A.
• Mounting: DIN 8 rail.

Dimensions and Additional Features

• Monitor dimensions: 222 x 154 x 11.5 mm.
• Plate dimensions: 94 x 154 x 11.5 mm (Impact resistance grade IK07).
• Impact and moisture protection : IP30 on monitor, IP65 on board.
• Supports up to 2 outdoor panels and 3 monitors per home.
• Operating temperature: -20ºC to +55ºC.
• Total weight: 2,466 kg.
• EAN 13: 8424299015224

Buy the Fermax WAY 2/L video intercom now

Get the best security and convenience for your home with the WAY 2/L video intercom kit . With its modern design, advanced technology, and easy installation, it's the ideal choice for homes and communities.
